The powerful sound of classic tube amplifiers
in compact shape.

Analog amplifier with digital IR loader

TUBE technology & IR CAB Simulation

About & download CAB SIM Application

SH7 Available soon

Discover the main features

REVERB

BOOST

SERVO

NOISE GATE

Clean, Crunch & Drive

What makes SH-7 Apogee special in comparison to previous designs is the built-in SERVO enhancer.
Installing SERVO in the amplifier has opened up many new sound creation possibilities.
SERVO plays the role of some kind of "soul post" of this amplifier and enriches the sound in a magical way that will definitely be loved.

The SERVO enriches the sound of instruments, adding the qualities which make playing more enjoyable and even more importantly, more inspiring. The feeling is that we are playing on much higher quality instruments than we actually are. Additionally, it makes the guitar very well set in the overall band mix. Perfectly complements the clean sound - especially enriches the sound of single coil pickups.

Good quality Reverb greatly complements guitar sound.

NOISE GATE minimizes interference that often occurs on stage and is picked up by sensitive guitar pickups, thus the overall sound is also more clear and dynamic.

The BOOST MODE allows instant increase of amp’s volume level. To control the BOOST MODE, a potentiometer and a footswitch are assigned. By tweaking the potentiometer, a desired volume can be set. Pressing the BOOST switch located on the top of the amp causes immediate access to previously set volume level. The BOOST function performs two features at the same time: it boosts a signal at the preamp's input giving extra compression and gaining the volume. The BOOST MODE is quite beneficial when a guitar solo has to be played.

The amplifier offers three different sounds - CLEAN, CRUNCH and DRIVE. Two separate channels with separate tone correction gives a lot of opportunities to create your own, personalized sound. The sound setting process is very simple and intuitive, it works the same way as in traditional tube amplifiers.

Classic Tube Guitar Amplifier

Four in one:

Analog amplifier made in Master Tube Design technologii.

The amplifier is equipped with a 4-way power output selector. It allows you to use speaker cabinets of any size, power and impedance.

The following power options are available:

12W, 20W, 40W and 90Wat

The amplifier automatically adjusts its operating parameters and can serve 4, 8 and 16 Ohm cabinets.

If you want to record your guitar or use the amplifier as a pre-amp without a cabinet then you have a special tool on board, an advanced loudspeaker simulator.

Signal from Line-out can be lead in different ways: with simulation, without simulation or both.

IR louder designed by AMT Electronics on board. It is possible to save 16 IR files of speaker cabinet simulation through the USB port.

A simulation of the microphone position is also available and provides additional possibilities of equalizing the colour of your sound at the line output.

Thanks to this solution you can get closer to the sound conditions of a classic set of speakers with a microphone setup. You get the right placement and sound of the instrument in the band's mix by transmitting the signal from the line output without using the speaker.

5 footswitches for immediate access to the amps five different modes:
Clean, Crunch, Drive, Boost, Mute.
Additional OUTPUTS for external controller.

Foot Controller

Clean, Crunch, Drive, Boost and Reverb.

Cabinet Simulator

IR loader on board.
16-possition selector of IR CAB SIM
Adjustment for microphone position.

Preamp

You can use Stomp-Head as a preamp without connection to cabinet.

Amplifier

This compact amp delivers enough loudness level for any stage size.

Basket

Buy now

Order

Order now

Specification:

Power stage efficiency: 200Watt
Power output selector: 90W, 40W, 20W, 12W
Speakers impedance auto detection: 4,8 and 16ohm
Tubes: 12AX7
2 channels: CLEAN+CRUNCH and LEAD
5 footswitches: CLEAN, CRUNCH, DRIVE, REVERB, BOOST

CHANNEL controls (CLEAN & LEAD):
GAIN, BASS, MIDDLE, MID-RANGE switch, TREBLE, PRESENCE, VOLUME

MASTER controls:
SERVO – analog enhancer level with SERVO GAIN switch
BOOST - access to set two different volume levels
REVERB
NOISE GATE
MUTE
input GAIN boost (switch +6dB)
RESONANCE – switch increasing the sound in the resonance range of the loudspeaker
Serial EFFECT LOOP
LINE OUTPUT with Speaker Simulation. Allows send linear signal with simulation (PIN) or without simulation (RING) or both simultaneously
EXTERNAL CONTROLLER INPUT for channel selector and BOOST
Voltage selector 230V/50Hz or 115V/60Hz
Dimensions: (H x W x D) 90 x 330 x 205 mm
Weight: 2,65kg

Manual

990EUR

Compare amplifiers

Stomp-Head 7.Apogee "plus"

Taurus compact guitar amplifier ,Taurus floor guitar amplifier , Taurus floor amp , tube guitar amplifier , Taurus Stomp Head SH7Apogee, Taurus Stomp-Head SH7 Apogee, lassic guitar amplifier, StompHead 7, Taurus SH7Apogee, Taurus SH7, Taurus Apogee

The Taurus Stomp-Head 7 is a fully analog design based on our own Master Tube Design technology. Extremely light and compact but still very powerful and versatile.

The amplifier is equipped with its own speaker simulator with an IR CAB SIM pulse loader. It provides possibility of sending earlier chosen impulse/sound to the mixer without the need to use traditional sound path through the microphone. The SH7 can also be use as a preamp without necessity of connecting a speaker cabinet.

If extensive sound creation capabilities is preferred, the SH-7.CE will be the right choice for you.

SH-7 can be used in various configurations:

as a classic amplifier with a speaker cabinet.
There are 4 power levels to choose from: 90W, 40W, 20W and 12W.
as a preamp connected directly to the mixer or sound system using output with built-in loudspeaker simulation.

Stomp-Head 7 as a pre-amp.
If you want to record your guitar or use the amplifier as a pre-amp without a cabinet then you have a special tool on board - an advanced loudspeaker simulator with IR louder, designed by AMT Electronics. It is possible to save 16 IR files of speaker simulation through the USB port.. More info about AMT CAB SIM: http://media.amt-sales.com/cat/cab-emulation/pangaea-series/
A simulation of the microphone position is also available and provides additional possibilities of equalizing the colour of your sound at the line output. Thanks to this solution you can get closer to the sound conditions of a classic set of speakers with a microphone setup. You get the right placement and sound of the instrument in the band's mix by transmitting the signal from the line output without using the speaker. All this is done in an analog way, very simple and intuitive, without the use other additional processors. The line output has two signals paths, with or without simulation. This feature also allows you to connect an external loudspeaker simulator. So you can use the built-in simulation, external simulation or both of them at once.

Taurus Custom

SH7 IR

SH7IR D

how to get a great guitar sound with Taurus Servo. TUBE EMULATOR, BUFOR, SUSTAINER, COMPRESSOR, BOOSTER.
